Cutting data consists of the items listed below.
For the meaning of cutting data, see Section 18.1, “CONTOUR
MACHINING”, in Part II, “PROGRAMMING”.
1) Setting items
Setting range
Without
additional cutting
condition
registration
With additional
cutting condition
registration
Feedrate 0 to 99999 0 to 99999 mm/min
Cutting peak power 0 to 9999 0 to 9999 W
Cutting frequency 5 to 2000 5 to 2000 Hz
Cutting duty 0 to 100 0 to 100 %
Assist gas pressure 0 to 9.99 0 to 9.99 MPa
Assist gas select 1 to 7 1 to 7
Gas settling time 0 to 9.9 0 to 9.9 Sec
Reference displace –9.999 to 9.999 –9.999 to 9.999 mm
Cutter compensation –9.999 to 9.999 –9.999 to 9.999 mm
Edge cutting select 0/201 to 205 0/201 to 215 Aux. data No.
Startup select 0/201 to 205 0/201 to 215 Aux. data No.
Power control
select
(*3)
0/901 to 910 0/901 to 910 Aux. data No.
*3 Supported by the FS16i–LB and later
2) Size
A group consists of 10 sets, each consisting of the above items, when
the option for additional cutting condition registration is not provided,
or a group consists of 30 sets when the option for additional cutting
condition registration is provided.
3) Calling method
If a cutting data set number is specified with address E in a program,
the data set with the specified number is read as active data and used
for control when the cutting feed command is executed.
E ;
The number of cutting data set (1 to 10
(*4)
, 1 to 30
(*5)
)
*4 Without the option for additional cutting condition registration
*5 With the option for additional cutting condition registration
D Cutting data group
