PROGRAMMING

B–63664EN/02

16. HIGH SPEED CUTTING FUNCTIONS

309

The functions listed below are valid in the AI contour control/AI nano

contour control mode:

⋅ Nano–interpolation (only in the AI nano contour control mode)

⋅ Look–ahead linear acceleration/deceleration before interpolation

⋅ Look–ahead bell–shaped acceleration/deceleration before interpolation

(The option of look–ahead bell–shaped acceleration/deceleration

before interpolation is required.)

⋅ Automatic corner deceleration

⋅ Feedrate clamping by acceleration

⋅ Feedrate clamping by arc radius

⋅ Block overlap (up to five blocks)

⋅ Advanced preview feed forward

Nano–interpolation calculates a position command to be output to the

digital servo in nanometers (nm) for a conventional program. Using the

calculation results, a smooth position command is output to the servo, so

the machine can be moved smoothly and the surface precision is

improved.

Combination with HRV

control improves the

follow–up ability.

Calculates the

position precisely.

Uses a conventional

program.

NC program

Nano–

interpolation

High–precision

servo control

Servo motor

NOTE

The positioning precision depends on the detection unit.

For a cutting feed command in the feed per minute mode, linear

acceleration/deceleration can be applied before interpolation, that is, for

the specified feedrate by reading up to 40 blocks (in the AI contour control

mode) or 180 blocks (in the AI nano contour control mode) in advance.

With acceleration/deceleration after interpolation, the interpolated data is

changed because acceleration/deceleration is applied to the data. With

acceleration/deceleration before interpolation, the interpolated data

cannot be changed by acceleration/deceleration because acceleration/

deceleration is applied to the feedrate data before interpolation. For this

reason, the interpolated data can always be applied to the specified

straight line or curve to eliminate machining profile errors caused by

acceleration/deceleration delays.

D Functions valid in the AI

contour control/AI nano

contour control mode

D Nano–interpolation (only

in the AI nano contour

control mode)

D Look–ahead linear

acceleration/deceleration

before interpolation
