AC Servo Motor Alpha i/is Series, Maintenance manual Page 117

Maintenance manual
B-65285EN/03 TROUBLESHOOTING 3.TROUBLESHOOTING AND ACTION
- 87 -
3.1.2 Alarm Code 2 (PSM, PSMR)
(1) Meaning
A cooling fan for the control circuit has stopped.
(2) Cause and troubleshooting
(a) Cooling fan broken
Check whether the cooling fan rotates normally.
→ Replace it.
3.1.3 Alarm Code 3 (PSM)
(1) Meaning
The temperature of the main circuit heat sink has risen
abnormally.
(2) Cause and troubleshooting
(a) Cooling fan for the main circuit broken
Check whether the cooling fan for the main circuit rotates
normally.
→ Replace it.
(b) Dust accumulation
→ Clean the cooling system with a vacuum cleaner or the
factory air blower.
(c) Overload
→ Examine the operating conditions.
(d) Poor installation of the control printed-circuit board
→ Be sure to push the faceplate as far as it will go. (This
alarm may be displayed if one of the connectors for
connection between the control printed-circuit board
and power printed-circuit board is detached.)
3.1.4 Alarm Code 4 (PSM, PSMR)
(1) Meaning
In the main circuit, the DC voltage (DC link) has dropped.
(2) Cause and troubleshooting
(a) A small power dip has occurred.
→ Check the power supply.
(b) Low input power supply voltage
→ Check the power supply specification.
(c) The main circuit power supply may have been switched off
with an emergency stop state released.
→ Check the sequence.
