3.4.3 Alarm Code 03
The fuse of the DC link has blown. (The voltage at the DC link is
insufficient.) This alarm is checked when emergency stop is cancelled.
(1) If this alarm is issued during spindle operation (rotation)
The fuse of the DC link inside the SPM has probably blown. So,
replace the SPM. This alarm may be caused by the following:
<1> Power lead short-circuited to ground
<2> Motor winding short-circuited to ground
<3> IGBT or IPM module failure
(2) If the PSM input magnetic contactor is once turned on and is
turned off with this alarm when emergency stop is cancelled or the
CNC is started (When two spindles are connected, the magnetic
contactor may not be turned off.)
(a) The DC link wire is not connected.
Check the DC link wiring for errors.
(b) The fuse of the DC link inside the SPM has blown.
Replace the SPM.
3.4.4 Alarm Code 06
The temperature sensor is abnormal, or the temperature sensor cable is
broken.
(1) The parameters specific to the motor are not correctly.
Referring to "FANUC AC SPINDLE MOTOR αi series
Parameter Manual (B-65280EN)," check the motor-specific
parameters.
(2) Cable is faulty.
Feedback cable is faulty.
Replace the cable.
(3) The control printed-circuit board is faulty.
Replace the control printed-circuit board or spindle amplifier.
(4) A thermo sensor is faulty.
Replace the motor (thermo sensor).
