B-65285EN/03 START-UP PROCEDURE 2.CONFIGURATIONS
- 7 -
2.2 MAJOR COMPONENTS
2.2.1 Power Supply Modules
(1) Power supply modules (PSM, 200VAC-input, power regeneration type)
Model
Order
specification
Unit specification Wiring board specification
Printed circuit board
specification
PSM-5.5i
A06B-6110-H006 A06B-6110-C006 A16B-2203-0640 A20B-2100-0760
PSM-11i
A06B-6110-H011 A06B-6110-C011 A16B-2203-0641 A20B-2100-0760
PSM-15i
A06B-6110-H015 A06B-6110-C015 A16B-2203-0642 A20B-2100-0760
PSM-26i
A06B-6110-H026 A06B-6110-C026 A16B-2203-0630 A20B-2100-0761
PSM-30i
A06B-6110-H030 A06B-6110-C030 A16B-2203-0631 A20B-2100-0761
PSM-37i
A06B-6110-H037 A06B-6110-C037 A16B-2203-0632 A20B-2100-0761
PSM-55i
A06B-6110-H055 A06B-6110-C055
A20B-1008-0081
(Driver PCB) A20B-2003-0420
A20B-2100-0761
(2) Power supply modules (PSM, 400VAC-input, power regeneration type)
Model
Order
specification
Unit specification Wiring board specification
Printed circuit board
specification
PSM-11HVi
A06B-6120-H011 A06B-6120-C011 A16B-2203-0647 A20B-2100-0760
PSM-18HVi
A06B-6120-H018 A06B-6120-C018 A16B-2203-0648 A20B-2100-0760
PSM-30HVi
A06B-6120-H030 A06B-6120-C030 A16B-2203-0636 A20B-2100-0761
PSM-45HVi
A06B-6120-H045 A06B-6120-C045 A16B-2203-0637 A20B-2100-0761
PSM-75HVi
A06B-6120-H075 A06B-6120-C075
A20B-1008-0086
(Driver PCB) A20B-2003-0420
A20B-2100-0761
PSM-100HVi
A06B-6120-H100 A06B-6120-C100
A20B-1008-0087
(Driver PCB) A20B-2003-0420
A20B-2100-0760
(3) Power supply modules (PSMR, 200VAC-input, resistance regeneration type)
Model
Order
specification
Unit specification
Printed circuit board
specification
PSMR-3i
A06B-6115-H003 A06B-6115-C003 A16B-2203-0781
PSMR-5.5i
A06B-6115-H006 A06B-6115-C006 A16B-2203-0782
