AC Servo Motor Alpha i/is Series, Maintenance manual Page 84

Maintenance manual
4.CONFIRMATION OF THE OPERATION START-UP PROCEDURE B-65285EN/03
- 54 -
(2) Internal data conversion
Data No. Signal name
Description (All are voltage values on check pins
when the shift amount is 8.)
218 IU Phase U current
219 IV Phase V current
The current is positive when it is
input to the amplifier. (*1)
162 VDC
DC link voltage signal
100V/1V (200 V system)
200V/1V (400 V system)
*1 Current conversion result for channels 218 and 219
Model Conversion result
SPM-2.2i
SPM-5.5i
16.7A/1V
SPM-11i
33.3A/1V
SPM-15i
50.0A/1V
SPM-22i
66.7A/1V
SPM-26i
100A/1V
SPM-30i
133A/1V
SPM-45i
150A/1V
SPM-55i
233A/1V
SPM-5.5HVi
SPM-11HVi
16.7A/1V
SPM-15HVi
33.3A/1V
SPM-30HVi
50.0A/1V
SPM-45HVi
66.7A/1V
SPM-75HVi
133A/1V
SPM-100HVi
150A/1V
(3) About the spindle control and spindle status signals
Shown below are the data numbers for the PMC signals used by
the spindle and the configuration of each data item. Refer to
Chapter 3, "PMC Signals (CNC ↔ PMC)" of "FANUC AC
SPINDLE MOTOR αi series PARAMETER MANUAL" (B-
65280EN) for explanations about each signal.
(a) Data number 6 : Spindle control signal 1
#15 #14 #13 #12 #11 #10 #9 #8
RCH RSL INTG SOCN MCFN SPSL *ESP ARST
#7 #6 #5 #4 #3 #2 #1 #0
MRDY ORCM SFR SRV CTH1 CTH2 TLMH TLML
(b) Data number 66 : Spindle control signal 2
#15 #14 #13 #12 #11 #10 #9 #8
DSCN SORSL MPOF
#7 #6 #5 #4 #3 #2 #1 #0
RCHHG MFNHG INCMD OVR NRRO ROTA INDX
