B-65285EN/03 START-UP PROCEDURE 2.CONFIGURATIONS
- 9 -
2.2.3 Spindle Amplifier Modules
The order specification varies according to the sensor (function) used.
(1) α
αα
αi series spindle amplifier modules (SPM, 200VAC-input)
TYPE A
Model Order specification Unit specification Wiring board specification
Printed circuit board
specification
SPM-2.2i
A06B-6111-H002 A06B-6111-C002 A16B-2203-0650 A20B-2100-0800
SPM-5.5i
A06B-6111-H006 A06B-6111-C006 A16B-2203-0651 A20B-2100-0800
SPM-11i
A06B-6111-H011 A06B-6111-C011 A16B-2203-0652 A20B-2100-0800
SPM-15i
A06B-6111-H015 A06B-6111-C015 A16B-2203-0653 A20B-2100-0800
SPM-22i
A06B-6111-H022 A06B-6111-C022 A16B-2203-0620 A20B-2100-0800
SPM-26i
A06B-6111-H026 A06B-6111-C026 A16B-2203-0621 A20B-2100-0800
SPM-30i
A06B-6111-H030 A06B-6111-C030 A16B-2203-0622 A20B-2100-0800
SPM-45i
A06B-6111-H045 A06B-6111-C045
A20B-1008-0090
(Driver PCB) A20B-2003-0420
A20B-2100-0800
SPM-55i
A06B-6111-H055 A06B-6111-C055
A20B-1008-0091
(Driver PCB) A20B-2003-0420
A20B-2100-0800
TYPE B
Model Order specification Unit specification Wiring board specification
Printed circuit board
specification
SPM-2.2i
A06B-6112-H002 A06B-6111-C002 A16B-2203-0650 A20B-2100-0801
SPM-5.5i
A06B-6112-H006 A06B-6111-C006 A16B-2203-0651 A20B-2100-0801
SPM-11i
A06B-6112-H011 A06B-6111-C011 A16B-2203-0652 A20B-2100-0801
SPM-15i
A06B-6112-H015 A06B-6111-C015 A16B-2203-0653 A20B-2100-0801
SPM-22i
A06B-6112-H022 A06B-6111-C022 A16B-2203-0620 A20B-2100-0801
SPM-26i
A06B-6112-H026 A06B-6111-C026 A16B-2203-0621 A20B-2100-0801
SPM-30i
A06B-6112-H030 A06B-6111-C030 A16B-2203-0622 A20B-2100-0801
SPM-45i
A06B-6112-H045 A06B-6111-C045
A20B-1008-0090
(Driver PCB) A20B-2003-0420
A20B-2100-0801
SPM-55i
A06B-6112-H055 A06B-6111-C055
A20B-1008-0091
(Driver PCB) A20B-2003-0420
A20B-2100-0801
(2) α
αα
αi series spindle amplifier modules (SPM, 400VAC-input)
TYPE A
Model Order specification Unit specification Wiring board specification
Printed circuit board
specification
SPM-5.5HVi
A06B-6121-H006 A06B-6121-C006 A16B-2203-0820 A20B-2100-0800
SPM-11HVi
A06B-6121-H011 A06B-6121-C011 A16B-2203-0821 A20B-2100-0800
SPM-15HVi
A06B-6121-H015 A06B-6121-C015 A16B-2203-0822 A20B-2100-0800
SPM-30HVi
A06B-6121-H030 A06B-6121-C030 A16B-2203-0627 A20B-2100-0800
SPM-45HVi
A06B-6121-H045 A06B-6121-C045 A16B-2203-0628 A20B-2100-0800
SPM-75HVi
A06B-6121-H075 A06B-6121-C075
A20B-1008-0096
(Driver PCB) A20B-2003-0420
A20B-2100-0800
SPM-100HVi
A06B-6121-H100 A06B-6121-C100
A20B-1008-0097
(Driver PCB) A20B-2003-0420
A20B-2100-0800
