AC Servo Motor Alpha i/is Series, Maintenance manual Page 68

Maintenance manual
4.CONFIRMATION OF THE OPERATION START-UP PROCEDURE B-65285EN/03
- 38 -
No. Description Action
18
Although parameter settings are such
that that there is no position sensor
(position control is not to be
performed, that is, "bits 3, 2, 1, and 0
of parameter No. 4002 are,
respectively, 0, 0, 0, and 0," a position
coder-based orientation command
has been issued.
Check the setting of the
parameter and the input signal.
19
Although magnetic sensor orientation
command is input, another operation
mode (Cs contour control, servo
mode, or spindle synchronization) is
specified.
Do not specify another mode
during execution of the orientation
command. Before entering
another mode, cancel the
orientation command.
24
Although continuous indexing in
position coder-based orientation is to
be performed, an absolute position
command (INCMD = 0) has been
issued after incremental operation
(INCMD = 1).
Check the INCMD (incremental
command).
Be sure to perform absolute
position command-based
orientation before an absolute
position command.
29
Parameter settings are such that the
shortest-time orientation function is to
be used (bit 6 of parameter No. 4018
is 0 and parameter Nos. 4320 to 4323
are nonzero).
The shortest-time orientation
function cannot be used in the αi
series spindle amplifier. Use a
different type of orientation.
31
This hardware configuration does not
support the use of the spindle FAD
function. In this case, the motor is not
activated.
Check the CNC model.
33
This hardware configuration does not
support the use of the spindle EGB
function. In this case, the motor is not
activated.
Check the CNC model.
34
Both spindle FAD function and
spindle EGB function are enabled. In
this case, the motor is not activated.
These functions cannot be used at
the same time. Enable only one of
the functions.
