AC SERVO MOTOR Alpha series Parameter manual Page 19

Parameter manual

Page of 482

/ 482

B-65150E/04 2. SETTING α SERIES SERVO PARAMETERS

− 13 −

α series servo motor

Servo software

Motor series

model and

motor type number

α1/3000 61 A B M A C A C A A E A

α2/2000 46 A B M A C A C A A E A

α2/3000 62 A B M A C A C A A E A

α2.5/3000 84 A B M A C A C A A E A

α3/3000 15 A B M A C A C A A E A

α6/2000 16 A B M A C A C A A E A

α6/3000 17 A B M A C A C A A E A

α12/2000 18 A B M A C A C A A E A

α12/3000 19 A B M A C A C A A E A

α22/1500 27 A B M A C A C A A E A

α22/2000 20 A B M A C A C A A E A

α22/3000 21 A B M A C A C A A E A

α30/1200 28 A B M A C A C A A E A

α30/2000 22 A B M A C A C A A E A

α30/3000 23 A B M A C A C A A E A

α40/FAN 29 ABMACACAAEA

α40/2000 30 A B M A C A C A A E A

α65 39 ABMACACAAEA

α100 40 A B M A C A C A A E A

α150 41 A B M A C A C A A E A

α300/2000 111 Y M K

α400/2000 112 Y M K

αL series servo motor

Servo software

Motor series

model and

motor type number

αL3/3000 56

ABMA

αL6/3000 57

ABMA

αL9/3000 58

ABMA

αL25/3000 59 A B M A C A C A A E A

αL50/3000 60 A B M A C A C A A E A

αC series servo motor

Servo software

Motor series

model and

motor type number

αC3/2000 7 A B M A C A C A A E A

αC6/2000 8 A B M A C A C A A E A

αC12/2000 9 A B M A C A C A A E A

αC22/1500 10 A B M A C A C A A E A
