AC SERVO MOTOR Alpha series Parameter manual Page 409

Parameter manual

Page of 482

/ 482

3/3Descri

tion

Desig



DateEd

01 00.04.26









Okita

Newl

desi

ned

Notice of the update of Digital

Servo Software 9090 series

B-65150E/04-008

FANUC LTD

Attached 1.

About the change of parameter table.

About the change of parameter table.About the change of parameter table.

About the change of parameter table.

We’ve changed following parameters.

Motor Model

2.5/3000

M2.5/3000

300/2000

400/2000

1000/2000

Motor Spec. 0374 0377 0137 0138 0131

Motor ID 84 99 115 116 117

Symbol

FS16,18,21,PM

No.

2003 00001000 00001000 00001000 00001000 00001000

2004 00000110 00000110 01000110 01000110 01000110

2005 00000000 00000000 00000000 00000000 00000000

2006 01000100 00000000 00000000 00000000 00000000

2010 00000000 00000000 00000000 00000000 00000000

2011 00000000 00000000 00100000 00100000 00100000

2012 00000000 00000000 00000000 00000000 00000000

2211 00000000 00000000 00000000 00000000 00000000

PK1 2040 368 400 1357 1593 1170

PK2 2041 -990 -1154 -4212 -5395 -3684

PK3 2042 -2455 -2547 -2710 -2711 -2722

PK1V 2043 70 56 114 113 264

PK2V 2044 -898 -500 -1023 -1016 -2362

PK3V 2045 0 0 0 0 0

PK4V 2046 -8235 -8235 -8235 -8235 -8235

POA1 2047 4228 -759 3709 3736 1606

POK1 2050 956 956 956 956 956

POK2 2051 510 510 510 510 510

PPMAX 2053 21 21 21 21 21

PDDP 2054 1894 1894 3787 3787 3787

PHYST 2055 319 319 319 319 319

EMFCMP 2056 1971 0 0 0 19379

PVPA 2057 2330 -8722 -3850 -2838 -3097

PALPH 2058 57 -1800 -800 -2000 -2000

PPBAS 2059 5 0 0 0 5

TQLIM 2060 7282 7282 7282 7282 6473

EMFLMT 2061 120 0 120 120 120

POVC1 2062 32569 32645 32352 32356 32027

POVC2 2063 2482 1535 5196 5145 9260

TGALMLV 2064 4 4 4 4 4

POVCLMT 2065 7376 4556 15494 15339 27750

AALPH 2074 0 8192 12288 12288 16384

RTCURR 2086 1644 1730 2385 2373 3193

DEPVPL 2098 50 0 0 0 0

ONEPSL 2099 400 400 400 400 400

DBLIM 2102 0 15000 15000 15000 15000

TRQCST 2105 131 143 10931 14398 25350

LP24PA 2106 0 0 0 0 0

MGSTCM 2110 0 2584 16 24 2334

DETQLM 2111 7730 7780 1606 1636 2607

NINTCT 2127 500 625 0 0 0

MFWKCE 2128 0 2500 5500 6500 6500

MFWKBL 2129 0 3847 791 784 1042

PHDLY1 2133 0 0 1556 1550 2581

PHDLY2 2134 0 0 20494 20494 15381

POVC21 2162 0 0 0 0 0

POVC22 2163 0 0 0 0 0

POVCLMT2 2164 0 0 0 0 0

MAXCRT 2165 40 25 365 365 365

The parameters for

current monitor on

servo tuning screen

were wrong. We’ve

corrected them.

Newly added
