AC SERVO MOTOR Alpha series Parameter manual Page 296

Parameter manual
4. SERVO FUNCTION DETAILS B-65150E/04
− 290 −
(c) Pin numbers and signal meanings
Pin
number
Signal
name
Signal meaning
Pin
number
Signal
name
Signal meaning
<1> <11> +24VC +24 V supply voltage
<2> +3.3V +3.3 V supply voltage <12> +15VC +15 V supply voltage
<3> IRL
L axis phase-R motor current
conversion signal
<13> −15VC −15 V supply voltage
<4> ISL
L axis phase-S motor current
conversion signal
<14> +5V +5 V supply voltage
<5> IRM
M axis phase-R motor current
conversion signal
<15> ITL
L axis phase-T motor current
conversion signal
<6> ISM
M axis phase-S motor current
conversion signal
<16>
<7> IRN
N axis phase-R motor current
conversion signal
<17> ITM
M axis phase-T motor current
conversion signal
<8> ISN
N axis phase-S motor current
conversion signal
<18>
<9> 0V GND <19> ITN
N axis phase-T motor current
conversion signal
<10> <20>
NOTE
1 If the SVM does not have an axis corresponding to a
pin on the check pin board, no signal is output to the
pin.
2 The voltage output using the motor current conversion
signal represents the actual current (sine wave)
flowing through the motor (4.0 V is output at maximum
current). This voltage cannot be measured with a
voltmeter (such as a VOM); use an oscilloscope.
