B-65150E/04 4. SERVO FUNCTION DETAILS

− 217 −

4.14 LINEAR MOTOR PARAMETER SETTING

4.14.1 Procedure for Setting the Initial Parameters of Linear Motors

(1) Overview

The following describes the procedure for setting the digital servo

parameters to enable the use of a FANUC linear motor.

(2) Series and editions of applicable servo software

Series 9066/D(04) and subsequent editions (Power Mate-D)

Series 9080/A(01) and subsequent editions (Series 15-B, 16-C, 18-C)

Series 9081/C(03) and subsequent editions (Series 15-B, 16-C, 18-C)

Series 9090/A(01) and subsequent editions (Series 16i, 18i, 21i, Power

Mate i)

Series 90A0/A(01) and subsequent editions (Series 15i, 16i, 18i, 21i,

Power Mate i)

(3) Setting parameters

The position and speed of a linear motor are detected by connecting a

linear encoder to the position detection circuit (A860-0333-T001,

A860-0333-T002).

The procedure for setting the linear motor parameters depends on the

signal pitch of the scale being used. So, check the signal pitch first.

Table 4.14.1 (a) Examples of usable linear encoders (incremental)

Scale maker Signal pitch (µm) Model

HEIDENHAIN 20 LS486, LS186, etc.

HEIDENHAIN 40 LB382, LIDA185, etc.

HEIDENHAIN 2 LIP481

HEIDENHAIN 4 LF481, LIF181, etc.

HEIDENHAIN 100 LB381

Mitsutoyo 20 AT402

Optodyne 40.513167 LDS

Rennyshore 20 RGBF

Table 4.14.1 (b) Usable linear encoders (absolute)

Scale maker Resolution (µm) Model

HEIDENHAIN 0.1 LC191F

Mitsutoyo 0.5 AT352

Refer to the "Fanuc Linear Motor Series Descriptions" (B-65222EN)

for details.
