AC SERVO MOTOR Alpha series Parameter manual Page 280

Parameter manual

Page of 482

/ 482

4. SERVO FUNCTION DETAILS B-65150E/04

− 274 −

NC name System software Servo software

Series 18-B BDA1/03 and later, or

BEA1/04 and later

Series 9070/H(08) and later,

Series 9080/A(01) and later

Series 18-C All versions can be used. Series 9080/A(01) and later

Series 21i (C52)

All versions can be used. Series 9090/A(01) and later

Series 21i (C543)

DDF1/08 and later, or

DEF1/08 and later

Series 90A0/A(01) and later

Series 21-TB DE01/06 and later Series 9060/W(23) and later

Series 21-MB D201/09 and later

DDA1/01 and later

Series 9060/W(23) and later

The following servo software can also be used:

• Series 9081/C(03) and later

• Series 9066/F(06) and later

<2> Auto tuning software produced by FANUC

• For NEC PC9801-series

Specification: A08B-9000-J900

• For IBM PC/AT compatible machines

Specification: A08B-9001-J900

(As of May, 1999, the latest edition is Edition 1.6.)

<3> Interface board manufactured by FANUC

Specification: A06B-6057-H630

<4> Cable 1 (for connection between the NC and interface board)

The required cable varies from one NC to another. For

detailed descriptions about connection, see Sec. 4.19, "Servo

Check Board Operating Procedure."

<5> Cable 2

NOTE

Only when a NEC PC9801-series PC is used, the

cable below (for connection between the interface

board and PIO48W manufactured by Contech) is to

be purchased from FANUC.

For a desktop personal computer

Specification: A06B-6050-K870

For a notebook-sized personal computer

Specification: A06B-6050-K869
