POWER MATE MODEL D/F Maintenance manual Page 112

Maintenance manual

Page of 420

/ 420

B–62835EN/01

2. HARDWARE

101

No. NAME Specification Function Display of system con-

figuration screen

Base PCB A16B–2201–0630 –

(1)

PMC controled module A A20B–2900–0142 PMC–PA1 PMC BIT

PMC controled module B A20B–2901–0660, 0662 PMC–PA3 PMC PMP+SLC

(2) Memory module A

A20B–2900–0531

RAM 128KB RAM 128KB

A20B–2902–0332

Memory module B

A20B–2900–0530

RAM 256KB RAM 256KB

A20B–2902–0331

Memory module C

A20B–2900–0541

RAM 512KB RAM 512KB

A20B–2902–0330

(3) CPU module A20B–2901–0500 CPU function –

(4) CRT controled module A20B–2901–0480 CRT, PDP SCA(CRT) 9”CRT

(5) Spindle module

A20B–2900–0851 Analog spindle POS LSI

A20B–2900–0850 Serial spindle SIC

A20B–2901–0210 Analog input + Serial spindle ANALOG INPUT

SIC

(6) Digital servo module A20B–2901–0340 E series servo

SERVO 1/2

(7) Digital servo interface module A20B–2900–0380 Servo interface function

(8) Power supply PCB A20B–1004–0960 Power supply –

(9) Sub PCB

A20B–2000–0670 Built–in I/O (sink type) BLT I/O

A20B–2001–0370 M–NET M–NET

(10) Basic ROM A02B–0166–H501

#8831

Basic function 8831
