APPENDIX

B. ALARM LIST

B–62835EN/01

374

12) ALARM

Number Message Contents Counter plan Reference

1000 to

1999

A message created by the user or

machine tool builder, using the PMC

alarm message function, is dis-

played.

NOTE) On the DPL/MDI, only the

number is displayed.

Alarm generated by

the user or machine

tool builder using the

PMC

Apply appropriate

countermeasures as

explained in the

manual provided by

the machine tool

builder.

Manual provided by

machine tool builder

3000 to

3200

A message created by the user or

machine tool builder, using a custom

macro, is displayed.

NOTE) On the DPL/MDI, only the

number is displayed.

Alarm generated by

the user or machine

tool builder, using a

custom macro

Apply appropriate

countermeasures as

explained in the

manual provided by

the machine tool

builder.

Manual provided by

machine tool builder

3000 to

3099

P/S ALARM Alarm generated by

the user or machine

tool builder, using the

PMC alarm display

function

Manual provided by

machine tool builder

Manual provided by

machine tool builder

5010 END OF RECORD EOR was read with-

out specifying a pro-

gram end command.

13) Alarm messages (PMC)

This list contains alarms which do not occur in the Power Mate–D/F.

Message Contents and solution

ALARM NOTHING Normal status

ER00 PROGRAM DATA

ERROR(ROM)

The ladder program is not written correctly.

(solution) Write the ladder program again.

ER03 PROGRAM SIZE

ERROR(OPTION)

The size of ladder program exceeds the option specification size.

(solution) Please increase the option specification size.

Or, reduce the size of ladder program.

ER04 PMC TYPE UNMATCH The PMC model setting of the ladder program is not corresponding to an actual model.

(solution) Please change the PMC model setting by the offline programmer.

ER05 PMC MODULE TYPE

ERROR

The module type of the PMC engine is not correct.

(solution) Please exchange the module of PMC engine for a correct one.

ER07 NO OPTION

(LADDER STEP)

There is no step number option of LADDER.

ER17 PROGRAM PARITY A parity error occurred in RAM containing a ladder program.

(solution) Please edit the sequence program once on PMC. Check the operation.

Still the error occurs, exchange the RAM.

ER18 PROGRAM DATA ERROR

BY I/O

Transferring the ladder program from offline programmer was interrupted by the power

off etc.

(solution) Please clear the ladder program and transfer the ladder program again.

ER19 LADDER DATA ERROR Editing the LADDER was interrupted by the power off or by the switch to the CNC screen

by the function key etc.

(solution) Please edit LADDER once on PMC.

Or, please input LADDER again.

ER20 SYMBOL/COMMENT

DATA ERROR

Editing the symbol and comment was interrupted by the power off or by the switch to the

CNC screen by the function key etc.

(solution) Please edit symbol and comment once on PMC.

Or, please input symbol and comment again.

ER21 MESSAGE DATA ERROR Editing the message data was interrupted by the power off or the switch to the CNC

screen by the function key etc.

(solution) Please edit message data once on PMC.

Or, please input message data again.
