B–62835EN/01

7. AC SPINDLE (ANALOG INTERFACE)

243

Name

Signal contents Remarks

DA2

Analog speed command

voltage (SVC)

0 to +10V, Rated speed at 10V

Pulse generator output

A–phase

90° advance by PB at CW rotation

p–p

=0.36–0.5V

Pulse generator output

B–phase

90° delay by PA at CW rotation

p–p

=0.36–0.5V

A–phase standard voltage +2.5VDC "0. 2V

B–phase standard voltage +2.5VDC "0. 2V

PAP

A phase pulse waveform Duty 50% (ON/ OFF ratio)

PBP

B phase pulse waveform Duty 50% (ON/ OFF ratio)

TSA

Speed feedback signal At maximum rated max. rotation

"10V(CW:+,CCW:–)

TS2

Low–speed detection

signal

At CCW (forward rotation)

22.5rpm , –1.4V"0.3V

TS3

Speed pulse F/V converi-

son signal

At CCW (forward rotation)

6000 rpm , –4.65 to –6.15V

VCMD

Speed command voltage 0X"10V, (CCW:+, CW: – )

TSAF

CCW rotation speed

detection signal

At CCW (forward rotation)

6000 rpm , 0. 82V "82mv

TSAR

CW rotation speed

detection signal

At CW (backward rotation)

6000 rpm , 0. 82V "82mv

Error voltage –4.2 to +4.8V

CLK1

Clock signal 2. 5MHz , duty 50%

SLIP

Slip pulse

VDC

DC link voltage signal Voltage 1/100 of DC link voltage

SDC

Control power DC link

voltage

Voltage 1/100 of control power DC link

voltage

ADIN

A/D converter input signal

U–phase current detection

signal

V–phase current detection

signal

W–phase current detec-

tion signal

+24V

+24V DC voltage About 23V "4%

+15V

+15V DC voltage +15V"4%

+5V

+5V DC voltage +5V"4%

–15V

–15V DC voltage –15V"4%

*RGHLD

Regenerative stop signal

7.2.2

Models 6S to 26S

(Amp. specification:

A06B–6059–H2xx)

Model 6S to 12S 15S to 22S 26S

Current 33.3 A/V 66.6 A/V 83.3 A/V

value
