POWER MATE MODEL D/F Maintenance manual Page 190

Maintenance manual

Page of 420

/ 420

B–62835EN/01

4.INTERFACE BETWEEN NC AND PMC

179

MODE INPUT/OUTPUT SIGNAL FEED RATE,

ETC

EDIT [PMC ⇒ CNC]

KEY3(Program protect key)

MEM

MDI

RMT

[PMC ⇒ CNC]

ST (Cycle start)

*SP (Feed hold)

SBK (Single block)

DRN (Dry run)

BDT1 to 9(Block delete)

MIα (Mirror image)

PN1 to 8 (External program no. search)

DNCI (DNC input mode)

HSα1A to B

(Handle interrupt axis select)

AFL (Auxiliary function neglect)

FIN (Auxiliary function complete)

MFIN, SFIN, TFIN

(High speed M/S/T function complete)

*SSTP (Spindle stop)

SAR (Spindle speed arrival)

SOR (Spindle orientation)

[PMC ⇒ CNC]

*FV0 to 7

(Feed rate over-

ride)

OVC

(Override can-

cel)

ROV1,ROV2,

HROV,

*HROV0 to 6,

(Rapid traverse

override)

SOV0 to 7

(Spindle speed

override)

[CNC ⇒ PMC]

STL (Cycle start LED)

SPL (Feed hold LED)

MF, M00 to M31 (Miscellaneous function)

SF, S00 to S31 (Spindle speed function)

TF, T00 to T31 (Tool function)

DEN (Distribution end)

OP (automatic operating)

GR1O ot GR3O (Gear selection)

MODE INPUT/OUTPUT SIGNAL FEED RATE,

ETC

Handle/

incremental

[PMC ⇒ CNC]

HSnA to B

(Axis selection) n:1 to 2(No. of

MPGs)

+α,– α (Jog feed)

[PMC ⇒ CNC]

MP1, MP2

(Multiplier)

JOG [PMC ⇒ CNC]

RT (Rapid traverse)

[PMC ⇒ CNC]

*JV0 to 15

(Manual fee

[PMC ⇒ CNC]

ZRN(Reference position return mode)

[MT ⇒ CNC]

*DECα (Reference position deceleration)

(Manual

fee-

drate override)

+α, –α (Man

ual feed move

command)

ROV1 ROV2

[CNC ⇒ PMC]

ZPα

ZP2α, ZP3α

(Reference position return completion)

ROV1

ROV2

(Rapid traverse

override)

4.5

LIST OF SIGNALS BY

EACH MODE

D Automatic operation

D Manual operation
