POWER MATE MODEL D/F Maintenance manual Page 405

Maintenance manual
APPENDIX
D. DATA INPUT/OUTPUT TO AND
FROM A MEMORY CARD
B–62835EN/01
396
The data that can be input/output to and from a memory card varies
according to the memory size of the power Mate.
 D.4 (a) Valid Data for Different Memory sizes of
the 1–path Power Mate–D
Data type
Power Mate–D memory size (bytes)
Data
type
128K 256K 512K 768K
Program f f f f
Parameter
Pitch error compensation data
f f f f
Variable data
Tool offset data
f f f f
Ladder f f f f
PMC data f f f f
Operation history data f f f
Macro executor f f
f : Valid data, : Invalid data
 D.4 (b) Valid Data for Different Memory sizes of
the 2–path Power Mate–D
Data type
Power Mate–D memory size (bytes)
Data
type
256K 512K 768K
Program f f f
Parameter
Pitch error compensation data
f f f
Variable data
Tool offset data
f f f
Ladder f f f
PMC data f f f
Operation history data f f
Macro executor f
f : Valid data, : Invalid data
 D.4 (c) Valid Data for Different Memory sizes of the Power Mate–F
Data type
Power Mate–F memory size
Program f
Parameter
Pitch error compensation data
f
Variable data
Tool offset data
f
Ladder f
PMC data f
f : Valid data, : Invalid data
D.4
DATA INPUT/OUTPUT
TO AND FROM A
MEMORY CARD
