APPENDIX

B–62835EN/01

C. LIST OF MAINTENANCE

PARTS

389

Maintenance Parts (Parts to be repaired by us)

Name Drawing number Vender Remarks Rank

FANUC,

Table mount

A02B-0168-C010 FANUC B

DPL/MDI

FANUC,

Wall mount

A02B-0168-C011 FANUC B

DPL/MDI

GEFanuc,

Table mount

A02B-0168-C012 FANUC B

GEFanuc,

Wall mount

A02B-0168-C013 FANUC B

FANUC,

Table mount

A02B-0118-C030 FANUC A02B-0118-C131,

C132, C133

Long direction type

FANUC,

Wall mount

A02B-0118-C031 FANUC A02B-0118-C130,

C132, C133

DPL/MDI

GEFanuc,

Table mount

A02B-0118-C032 FANUC A02B-0118-C130,

C131, C133

GEFanuc,

Wall mount

A02B-0118-C033 FANUC A02B-0118-C130,

C131, C132

FANUC,

Table mount

A02B-0118-C130#R FANUC For CE marking A02B-0118-C131#R,

C132#R, C133#R

A02B-0118-C130#S FANUC For CE marking A02B-0118-C131#S,

C132#S, C133#S

FANUC,

Wall mount

A02B-0118-C131#R FANUC For CE marking A02B-0118-C130#R,

C132#R, C133#R

Dust

rotected ty

A02B-0118-C131#S FANUC For CE marking A02B-0118-C130#S,

C132#S, C133#S

rotected

ty e

DPL/MDI

GEFanuc,

Table mount

A02B-0118-C132#R FANUC For CE marking A02B-0118-C130#R,

C131#R, C133#R

A02B-0118-C132#S FANUC For CE marking A02B-0118-C130#S,

C131#S, C133#S

GEFanuc,

Wall mount

A02B-0118-C133#R FANUC For CE marking A02B-0118-C130#R,

C131#R, C132#R

A02B-0118-C133#S FANUC For CE marking A02B-0118-C130#S,

C131#S, C132#S

LCD A61L-0001-0110#A HITACHI Usable uint

A02B-0168-C010 to C013

A02B-0118-C030 to C033

A02B-0118-C130#R to C133#R

A02B-0118-C130#S to C133#S
