POWER MATE MODEL D/F Maintenance manual Page 404

Maintenance manual

Page of 420

/ 420

APPENDIX

B–62835EN/01

D. DATA INPUT/OUTPUT TO AND

FROM A MEMORY CARD

395

- Inputting specific data

(1) Place the Power Mate in either EDIT or MDI mode.

(2) Place the system in the emergency stop state.

(3) Set setting parameter [parameter write] to 1.

(When the DPL/MDI is used, set [PWE] to 1.)

(4) Press the <PRGRM> display button to display the program display

screen.

(5) Insert the memory card in the Power Mate.

(6) Enter address <M>.

(7) Specify the types of data to be input by using numeric characters in

the form <n7n6n5n4n3n2n1>.

n1 : Program

n2 : Parameter, Pitch error compensation

n3 : Variable, tool length compensation data

n4 : Ladder program

n5 : PMC data

n6 : Operation history data

n7 : Macro executor

Specifying 1 causes the corresponding data to be read. Specifying 0

causes the corresponding data to be skipped.

(8) Select [OPERATION], [→] and [READ], then press [EXEC].

(When the DPL/MDI is used, press the [READ] key.)

The specified data is then read into the Power Mate memory.

NOTE

1 The operation history data can be read for a 256–K, 512–K,

or 768–K 1–path Power Mate–D or 512–K or 768–K 2–path

Power Mate–D.

2 The macro executer can be read for a 512–K or 768–K

1–path Power Mate–D or 768–K 2–path Power Mate–D

system.

3 For a 2–path Power Mate–D, data for currently displayed

path is read.
