8.TROUBLESHOOTING

259

It shows that positioning is not yet completed. Check the contents of the

following diagnostic number. (It is 1 in the following condition)

DGN 0300

Position Error

>PARAM 1826

In–positio width

1 Check the parameters according to the parameter list

1825 Servo loop gain per axis (Normal : 3000)

2 Servo system may be abnormal. Refer to alarm 400, 410, and 411.

There are a plural interlock signals. Check at first which interlock signal

is used by the machine tool builder at the parameters shown below.

#7 #6 #5 #4 #3 #2 #1 #0

3003 DIT ITX HITL ITL

#0 ITL=0 shows interlock signal *IT is effective. To 1

#1 HITL = 1 shows interlock signal *RILK is effective. To 2

#2 ITX=0 shows interlock signal *ITn is effective. To 3

#3 DIT=0 shows interlock signal "MITn is effective. To 4

Check state of effective interlock signals using the diagnostic function

(PMCDGN) of the PMC.

1 Interlock signal (*IT) is input

#7 #6 #5 #4 #3 #2 #1 #0

G0008 *IT

*IT=0 shows that interlock signal is input.

2 High–speed interlock signal (*RILK) is input.

#7 #6 #5 #4 #3 #2 #1 #0

X0000 *RILK

X1000

*RILK = 0 shows interlock signal is input.

3 Axis interlock signal (*ITn) is input

#7 #6 #5 #4 #3 #2 #1 #0

G0130 *IT2 +IT1

*ITn=0 shows interlock signal is input.

4 Interlock signal per axis and direction (+/– MITn) is input

#7 #6 #5 #4 #3 #2 #1 #0

G0132 +MIT2 +MIT1

G0134 –MIT2 –MIT1

"MITn=1 shows interlock signal per axis and direction is input.

Check the signals using PMC’s diagnostic function (PMCDGN)

#7 #6 #5 #4 #3 #2 #1 #0

G0010 *JV7 *JV6 *JV5 *JV4 *JV3 *JV2 *JV1 *JV0

G0011 *JV15 *JV14 *JV13 *JV12 *JV11 *JV10 *JV9 *JV8

When the override is 0% all bits of the above address becomes

1111 1111 or 0000 0000.. . . . . . . . .

a. In–position check is

being done

b.Interlock signal is input

c. Jog feedrate override is
