POWER MATE MODEL D/F Maintenance manual Page 160

Maintenance manual
B–62835EN/01
3. INPUT AND OUTPUT OF DATA
149
1 Make sure the output device is ready for output.
2 Specify the punch code system (ISO or EIA) using a parameter.
3 Press the EDIT switch on the machine operator’s panel.
4 Press function key
SYSTEM
.
5 Press the rightmost soft key
(next–menu key) and press chapter
selection soft key
[PITCH].
6 Press soft key [(OPRT)].
7 Press rightmost soft key
(next–menu key).
8 Press soft keys [PUNCH] and [EXEC].
All parameters are output in the defined format.
1 Select the EDIT mode.
2 Press the
key to display the pitch error compensation data screen.
3 Press the
key.
4 When necessary, perform a file head search.
CAUTION
For a system using an absolute pulse coder, zero point
setting is required once all parameters have been input.
1. Set to the emergency stop state.
2. Confirm that the patameters required to input data is correct.
1) Press
key several times, and press [SETING] to display
SETTING screen.
2) Parameters can be rewritten when PARAMETER WRITE ENABLE
is 1.
3) Press
key to select the parameter screen.
4)
Address
0020 Selectionof I/O channel
l0 : Channel 1 (JD5 of connector)
1 : Channel 1 (JD5 of connector)
I/O channel=0 Set parameters 0101, 0102, 0103
I/O channel=1 Set parameters 0111, 0112, 0113.
3.2.8
Outputting Pitch Error
Compensation Data
Procedure (CRT/MDI)
Procedure (DPL/MDI)
3.2.9
Inputting CNC
Parameters
D Procedure (CRT/MDI)
