B–62835EN/01

1. DISPLAY AND OPERATION

Mode selection signals and rapid traverse override signals

are displayed as indicated below:

Input signal

Name displayed

MD1 ND2 MD4 ZRN DNCI

Name

displayed

0 0 0 0 0 MDI

1 0 0 0 0 MEM

1 0 0 0 1 RMT

0 1 0 0 0 NOMODE

1 1 0 0 0 EDT

0 0 1 0 0 H/INC

1 0 1 0 0 JOG

1 0 1 1 0 ZRN

0 1 1 0 0 TJOG

1 1 1 0 0 THND

Input signal

Name displayed

RV1 RV2

Name

displayed

0 0 R 100%

1 0 R 50%

0 1 R 25%

1 1 R F0%

(3) NC alarms

NC alarms are displayed in reverse video.

P/S alarms, system alarms, and external alarms are displayed together

with their numbers.

For other types of alarms, only the alarm type is displayed. (No details

are displayed.)

Example)

P/S0050, SV_ALM

(4) Time stamp (date and time)

The following time data (date and time) is recorded:

1) Date and time of power–on

2) Date and time of power–off

3) Date and time when an NC alarm occurs

(a) The power–on time is displayed as shown below:

92/01/20 ==== Year/Month/Day

09:15:30 ==== Hour:Minute:Second

(b) The power–off time and the time when an NC alarm occurred are

displayed in reverse video.

92/01/20

==== Year/Month/Day

09:15:30

==== Hour:Minute:Second

If a system alarm occurs, the date and time are not recorded.
