4. INTERFACE BETWEEN NC AND PMC

B–62835EN/01

174

(b) Press the key.

The counter data type is set.

5 Pressing the

or key displays the PMC programmer menu.

Selecting EDIT on the PMC programmer menu displays the editing

menu.

1 Display the PMC programmer menu.

2 Display the EDIT item by pressing the

or key.

PMC PRG MENU 2/3

>EDIT

3 Press the or key. The PMC editing menu appears.

PMC EDIT 1/1

>LADDER

To end editing and display the PMC programmer menu, press the or

key.

(1) Starting ladder mnemonics editing

Selecting LADDER on the PMC programmer menu displays the

ladder mnemonics editing screen. If the sequence program is

running, selecting this function automatically stops the program.

1 Display the PMC programmer menu.

2 Display the LADDER item by pressing the

or key.

PMC EDIT 1/1

>LADDER

3 Press the or key. The sequence program is displayed.

> N0001

RD X0000.0

Step number

Instruction

(2) Confirming the ladder mnemonics

1 Cursor scroll (scroll per step)

Pressing the

cursor key displays the instruction one step before

that currently displayed. Pressing the

cursor key displays the

instruction one step after that currently displayed.

4.4.3

Editing the Sequence

Program (Edit)

4.4.4

Editing Ladder

Mnemonics
