8. TROUBLESHOOTING

B–62835EN/01

276

Check whether it is a trouble of display or a trouble of the system.

Check the STATUS LED on the controller shows the following state.

EW (green) ON

WD (red) OFF

S0.SI –

If the status shows the above state, the system is normal.

Therefore, display system may be faulty.

If you have a DPL/MDI, check whether it can be used to manipulate the

system.

If the status shows other state, a hardware other than the display system

may be troublesome.

If the message ”WAITING FOR CRT DATA” appears on the CRT/MDI

unit, it indicates that the CRT/MDI unit has started normally.

(1) Confirmation item

Determine which of the following problems are evident.

1. Nothing is displayed on the CRT/MDI unit.

2. Only the message ”WAITING FOR CRT DATA” appears on the

CRT/MDI unit.

3. A position display appears on the CRT/MDI unit, and the keys

are ineffective.

(2) Causes and remedies

1. If nothing is displayed on the CRT/MDI unit.

D The power being supplied to the CRT/MDI unit is abnormal

(check the power supply).

D The CRT/MDI unit is defective (replace the CRT/MDI unit).

2. If only the message ”WAITING FOR CRT DATA” appears on the

CRT/MDI unit.

D Incorrect cable connection (correct)

D Defective cable (repair or replace)

D Defective CRT control module (replace)

D No CRT control module installed (install)

D Touch panel connection module or HSSB connection

module installed in place of the CRT control module (install

the CRT control module)

D Incorrect setting of rotary switches RSW and MTSW (correct

the setting)

3. A position display appears on the CRT/MDI unit, and the keys

are ineffective.

D DPL/MDI left connected (remove)

D Defective cable (repair or replace)

8.8

WHEN

MANIPULATION IS

NOT POSSIBLE WITH

THE CRT/MDI

Points

Judgement of the point

Causes and remedies

1. When the display system

is in toruble
