POWER MATE MODEL D/F Maintenance manual Page 38

Maintenance manual

Page of 420

/ 420

B–62835EN/01

1. DISPLAY AND OPERATION

The Power Mate–D uses the CRT/MDI for diagnosis display, while the

Power Mate–F uses the DPL/MDI.

(1) Press

SYSTEM

key on the CRT/MDI.

(2) Press soft key [DGN], then a diagnostic screen is displayed.

(1) Press the key to select the diagnosis screen.

When PMC data is displayed, operate 

Number 

in turn.

> @0001 0

@0002 1

Following are display methods in the diagnostic screen of PMC data.

(2) Press the key of the PMC address to be displayed.

(Use the bottom left address of the key.)

> @0001 0

D_ 0

Example: Display the address

data for D0100

(3) Enter the number of the PMC address to be displayed.

> @0001 0

D0100

(4) Press the key.

> D0100 000000000

D0100 000001010

By pressing the and keys, the cursor can be moved within the

PMC address being displayed.

1.6

DISPLAYING

DIAGNOSTIC PAGE

1.6.1

Displaying of CRT/MDI

1.6.2

Displaying of DPL/MDI
