4. INTERFACE BETWEEN NC AND PMC

B–62835EN/01

210

Symbol PMC addressSignal name

ZP1, ZP2 Reference position return end signal F094#0, #1

ZP21, ZP22 2nd reference position return end signal F096#0, #1

ZP31, ZP32 3rd reference position return end signal F098#0, #1

ZPEXT1, ZPEXT2 External reference position setting signal G212#6, G213#6

ZR1, ZR2 Dogless reference position setting signal G212#4, G213#4

ZRF1, ZRF2 Reference position establishment signal F120#0, #1

ZRN Manual reference position return selection signal G043#7

ZRNO Reference position return signal (software operator’s panel) F073#4
