8. TROUBLESHOOTING

B–62835EN/01

258

Operation mode status is displayed on the lower part of CRT as

follows :

If nothing is displayed, mode select signal is not input. Check

mode select signal using PMC’s diagnostic function

(PMCDGN).

For details, refer to section 1.7 STATUS DISPLAY.

(Example of display)

JOG : Manual continuous feed (JOG) mode

STEP : Manual handle/Step feed (HANDLE/STEP)

MDI : Manual data input (MDI) mode

AUTO : Automatic operation (Memory) mode

EDIT : EDIT (Memory edit) mode

#7 #6 #5 #4 #3 #2 #1 #0

G0043 MD4 MD2 MD1

Manual continuous (JOG) mode 1 0 1

Manual handle/Step feed (HANDLE/STEP) mode 1 0 0

Manual data input (MDI) mode 0 0 0

Automatic operation (AUTO) mode 0 0 1

EDIT (Memory edit) mode 0 1 1

±±±

TEACH IN STEP/HANDLE 1 1 1

TEACH IN JOG 1 1 0

(2) Check diagnostic data 000 to 025 of the CNC Check an item for which

1 is displayed

No. Message Display

000 WAITING FOR FIN SIGNAL : 0

001 MOTION : 0

002 DWELL : 0

a.003 IN–POSITION CHECK : 0

004 FEEDRATE OVERRIDE 0% : 0

b.005 INTERLOCK (Example) : 1

010 PUNCHING : 0

011 READING : 0

012 WAITING FOR (UN) CLAMP : 0

c.013 JOG FEEDRATE OVERRIDE 0% : 0

d.014 WAITING FOR RESET, ESP, RRW OFF : 0

015 EXTERNAL PROGRAM NUMBER SEARCH : 0

Items with a to d relate with manual and automatic operation and its

detail is shown below.
