8. TROUBLESHOOTING

287

This alarm is generated when absolute pulse coder battery becomes low.

If alarm 306 occurs, the reference position has been lost. After replacing

the battery, re–set the reference position.

WARNING

When replacing the memory backup batteries, keep the

power to the machine (CNC, servo amplifier) switched on,

and hold the machine at an emergency stop. Because this

work must be carried out while the power is kept switched

on and the cabinet is open, only the personnel who have

been trained for safety are allowed to engage in the work.

When replacing the batteries, be careful not to touch the

high–voltage circuit section (marked and shielded with

a shock hazard prevention cover). If you touch the

high–voltage circuit section when it is uncovered, you will

get an electric shock.

Replace the batteries in the α series servo amplifier module, the β series

servo amplifier, or the separate battery box.

CAUTION

1 When replacing the built–in batteries for the  series servo

amplifier module or β series servo amplifier module, keep

the power to the servo amplifier switched on.

2 When replacing the batteries in the separate type battery

box, keep the power to the NC and servo amplifier switched

on.

3 Note that we are not supposed to replace the batteries for

the control unit (for memory backup).

8.14

ALARM 306 TO 308

(ABSOLUTE PULSE

CODER BATTERY IS

LOW)

Absolute pulse coder

battery replacement

Procedure
