8.TROUBLESHOOTING

267

(1) Check manual operation is possible.

(2) Check the status of cycle start LED on machine operator’s manual.

(3) Check status of Power Mate.

When manual operation is either impossible, perform countermeasure,

based on the previous item ”Jog operation cannot be done”.

Confirm that a correct mode is selected according to the mode select status

of Power Mate status display. Also, by confirming the automatic

operation status it is possible to identify cycle operation, feed hold and

cycle stop state.

”****” is displayed at status display on CRT.

(1) Mode select signal is not correct.

When the mode select signal is input correctly, following status

display is done.

MDI :Manual data input mode (MDI)

AUTO :Automatic operation mode

RMT :Remote operation mode

If status display does not show a correct status, check the mode signal

with following diagnosis function of PMC side (PMCDGN).

#7 #6 #5 #4 #3 #2 #1 #0

G0043 DNCI MD4 MD2 MD1

DNCI MD4 MD2 MD1 Mode select

– 0 0 0

Manual data input mode (MDI)

0 0 0 1

Memory operation mode (AUTO)

1 0 0 1

Remote operation mode

(2) Cycle start signal is not input

This signal turns 1 when cycle start button is pressed and turns 0 when

it is released. The cycle start actuates when it changes from 1 to 0.

Check the state of the signal using PMC’s diagnostic

function(PMCDGN).

#7 #6 #5 #4 #3 #2 #1 #0

G0007 ST

#2 (ST) : Cycle start signal

The cycle is allowed to start by setting of parameter (No.3001#1)

when it changes from 1 to 0.

(3) Feed hold signal is input

Under normal state, the feed hold signal is 1 when the feed hold button

is not pressed.

Check the state of this signal using the PMC’s diagnostic function

(PMCDGN) .

#7 #6 #5 #4 #3 #2 #1 #0

G0008 *SP

#5 (*SP): Feed hold signal

8.6

AUTOMATIC

OPERATION

CANNOT BE DONE

Points

Causes and Remedies

1. When cycle operation is

not started (Cycle start

LED does not light)
