1. DISPLAY AND OPERATION

B–62835EN/01

#7 #6 #5 #4 #3 #2 #1 #0Address

0204 OFS MCC LDA PMS

DGN

#6(OFS): Abnormal current value result of A/D conversion of digital

#5(MCC):Contacts of MCC of servo amplifier is melted.

#4(LDA): Serial pulse coder LED is abnormal

#3(PMS): Feedback is not correct due to faulty serial pulse coder C or

feedback cable.

Address

0300 Position error of an axis in detection unit

DGN

Position error=

Feed rate [mm/min]

60 servo loop gain [1/sec]

Detection unit

Address

0301 Distance from reference position of an axis in detection unit

DGN

#7 #6 #5 #4 #3 #2 #1 #0Address

0400 SAI SSR POS SIC

DGN

This data indicates the offset data received by the CNC while it is

calculating the machine coordinates.

#4(SAI) 0 : Spindle analog control is not used.

1 : Spindle analog control is used.

#2(SSR) 0 : Spindle serial control is not used.

1 : Spindle serial control is used.

#1 (POS) A module required for spindle analog control is

0 : not mounted

1 : mounted

#0 (SIC) A module required for spindle serial control is

0 : not mounted

1 : mounted

Address

0401 Serial spindle alarm state of 1st spindle

DGN

#7 #6 #5 #4 #3 #2 #1 #0Address

0408 SSA SCA CME CER SNE FRE CRE

DGN

#0 (CRE): A CRC error occurred. (Warning)

#1 (FRE): A framing error occurred. (Warning)

#2 (SNE): The transmission/reception target is invalid.

#3 (CER): An error occurred during reception.

#4 (CME): No response was returned during automatic scanning.

#5 (SCA): A communication alarm occurred on the spindle amplifier side.

#7 (SSA): A system alarm occurred on the spindle amplifier side.

(These problems cause spindle alarm 749. Such problems are mainly

caused by noise, disconnection, or instantaneous power–off).

D Position error amount

D Machine position

D Serial spindle
