POWER MATE MODEL D/F Maintenance manual Page 135

Maintenance manual
2. HARDWARE
B–62835EN/01
124
1 Remove the power PC board as in 2.8.2 above.
2 Remove the two screws from the fan motor on the power PC board,
and replace the fan motor with a new one.
3 Mount the power PC board on the base PC board as in 2.8.2 above,
and return the base PC board to the case.
4 Reconnect the cables.
1 Turn off the power to the CRT/MDI, separated type CRT/MDI unit
and controller.
2 The CRT control PCB is located behind the MDI.
Remove all cables connected to the PCB.
3 Remove the square screws from the CRT control board, and replace
the PCB.
4 Reconnect the cables.
CAUTION
When the picture display CRT/MDI unit or separate picture
display MDI unit is being used, reload the picture screen
data.
2.8.3
The Fan motor
2.8.4
The CRT Control
Printed Circuit Board
