6. AC SPINDLE (SERIAL INTERFACE)

237

Standard parameters those are specific to each motor model can be set at

a time by this operation.

Note that, however, depending on the conditions under which a motor is

used, the machine tool builder may determine unique values to the

parameters.

Therefore, always set the parameters (No.4000 and later) according to the

parameter list attached to the machine.

1. Turn on power under emergency stop condition.

2. Set PRM4019#7 to 1.

LDSP4019

#6 #5 #4 #3 #2 #1 #0

#7(LDSP) Serial interface spindle parameters are:

0 : Not set automatically.

l 1 : Set automatically.

3. Set a motor model code.

4133 Motor model code

3S (1500/6000rpm)

6S (1500/6000rpm)

8S (1500/6000rpm)

12S(1500/6000rpm)

15S(1500/6000rpm)

18S(1500/4500rpm)

30S(1150/4500rpm)

8P (750/6000rpm)

12P(750/6000rpm)

15P(750/6000rpm)

Motor modelCode

18P (750/6000rpm)

22P (750/6000rpm)

40P (575/4500rpm)

30P (575/4500rpm)

50P (575/4500rpm)

1S (3000/8000rpm)

1.5S (1500/8000rpm)

2S (1500/8000rpm)

3S (1500/6000rpm)

0.5S (3000/8000rpm)

Code

Motor model

4. Turn off power once, then turn it on again.

“PLoAd” is displayed on the spindle amplifier PCB and the standard

parameters are read.

6.5

AUTOMATIC

SETTING OF

STANDARD

PARAMETER
