POWER MATE MODEL D/F Maintenance manual Page 212

Maintenance manual

Page of 420

/ 420

B–62835EN/01

4.INTERFACE BETWEEN NC AND PMC

201

Address Bit No.

#7 #6 #5 #4 #3 #2 #1 #0

F054

UO7 UO6 UO5 UO4 UO3 UO2 UO1 UO0

F055 UO15 UO14 UO13 UO12 UO11 UO10 UO9 UO8

F056 UO107 UO106 UO105 UO104 UO103 UO102 UO101 UO100

F057 UO115 UO114 UO113 UO112 UO111 UO110 UO109 UO108

F058 UO123 UO122 UO121 UO120 UO119 UO118 UO117 UO116

F059 UO131 UO130 UO129 UO128 UO127 UO126 UO125 UO124

F065 RGSPM RGSPP

F070 PSW08 PSW07 PSW06 PSW05 PSW04 PSW03 PSW02 PSW01

F071 PSW10 PSW09

F094 ZP1

F096 ZP21

F098 ZP31

F104 INP1

F106 MVD1

F110 MDTCH1

F120 ZRF1

F129 *EAXSL EOV0

F130 EBSYA EOTNA EOTPA EGENA EDENA EIALA ECKZA EINPA

F131 EMFA

F132 EM28A EM24A EM22A EM21A EM18A EM14A EM12A EM11A

F180 CLRCH0

F208 SVER1 IPL1 SUP1

F209 CTOPN RTPT WVRDY WAT4 WAT3 WAT2 WAT1

F210 K7 K6 K5 K4 K3 K2 K1 K0

F211 KCAN KEOB KSLH KNO KPRD KMNS K9 K8

F212 KRED KWRT KINP KDLT KINS KALT

CNC  PMC
