APPENDIX

B–62835EN/01

B. ALARM LIST

369

The details of serial pulse coder alarm No. 351 (communication alarm)

are displayed in the diagnosis display (No. 203) as shown below.

#7 #6 #5 #4 #3 #2 #1 #0

DTE

CRC

STB PRM203

DTE : The serial pulse coder encountered a communication error.

The pulse coder, feedbak cable, or feedback receiver circuit is

defective. Replace the pulse coder, feedback cable, base PCB, or

servo module.

The servo interface type (A or B) is incorrect.

CRC: The serial pulse coder encountered a communication error.

The pulse coder, feedback cable, or feedback receiver circuit is

defective. Replace the pulse coder, feedback cable, base PCB, or

servo module.

STB : The serial pulse coder encountered a communication error.

The pulse coder, feedback cable, or feedback receiver circuit is

defective.

Replace the pulse coder, feedback cable, base PCB, or servo

module.

PRM: An invalid parameter was found. Alarm 417 (invalid servo

parameter) is also issued.

D The details of serial

pulse coder alarm

No.351
