1. SCREEN DISPLAY AND OPERATION

1.6.3 Displaying and setting the offset values for the workpiece

coordinate system

(1) Press soft key [WORK].

NO. DATA

02 X 152.580

(G55) Z 58.284

03 X 300.000

(G56) Z 200.000

OFFSET

[][][][][]

SETING WORK (OPRT)

WORK COORDINATES O0100 N00001

NO. DATA

00 X 0.000

(EXT) Z 0.000

01 X 100.000

(G54) Z 50.000

MEM **** *** *** 16:24:18

(2) Operation

Coordinate system number

[NO.SRH]Soft key [(OPRT)]

Compensation value

[+INPUT]

Axis

[MEASUR]

Numeral

Compensation value

[INPUT]

(3) Related parameters

PRM3290#3 (WZO): Entering shift values of the coordinate system

(T series) or offsets from the workpiece

reference position (M series) from the MDI panel

is allowed/inhibited.

PRM1220:External shift value of the workpiece coordinate system (T

series).

External offset from the workpiece reference position (M

series)

PRM1221:Offset from the workpiece reference position for G54

PRM1222:Offset from the workpiece reference position for G55

PRM1223:Offset from the workpiece reference position for G56

PRM1224:Offset from the workpiece reference position for G57

PRM1225:Offset from the workpiece reference position for G58

PRM1226:Offset from the workpiece reference position for G59
