13.2 Diagnosis Information (DGN) List

770

Alarm

detail

No.

ActionCause

Param-

eter No.

994

995

996

2099 The internal value for N

pulse suppression over-

flowed.

Disable the N pulse sup-

pression function (by setting

PRM2003#4 to 0).

Alternatively, decrease the

value of this parameter so

that no overflow occurs.

1033 2103 The withdrawal amount for

abnormal load is different

between the L axis and M

axis (when the same axis

withdrawal function is used).

Set the same value for the L

axis and M axis.

1123 2112 When a linear motor is used,

the AMR conversion coeffi-

cient parameter is not input.

Specify an AMR conversion

coefficient.

1182 2118

2078

2079

The dual position feedback

conversion coefficient is not

set.

Specify a dual position feed-

back conversion coefficient.

1183 2118 When the closed loop is set

for a linear motor, this pa-

rameter is not set.

When the closed loop is set

for a linear motor, this pa-

rameter is a mandatory pa-

rameter. Specify a proper

value.

1284

1285

2128 When the specified number

of velocity pulses is small,

the internal value of the pa-

rameter related to current

control overflows.

Decrease the value of this

parameter to such a value

that the alarm is not issued.

1294

1295

2129 When the specified number

of velocity pulses is large,

the internal value of the pa-

rameter related to current

control overflows.

Resolve the setting of this

parameter into a256+b,

and set a new value by de-

creasing the value of a.

1393 2139 The setting of the linear mo-

tor AMR offset value ex-

ceeded ±45.

Change the setting of this

parameter to within ±45.

Alternatively, set PRM2270

#0 to 1 and increase the

AMR offset setting range,

then set a value within ±60.

1446

1447

1448

2144 The cutting feed–forward

factor for the cutting/rapid

traverse–specific FAD func-

tion overflowed.

Use the position gain in-

crease function.

1454

1455

1456

1459

2145 The cutting velocity feed–

forward factor for the cutting/

rapid traverse–specific FAD

function overflowed.

Increase the velocity feed–

forward factor.

1493 2149 A value greater than 6 is set

in this parameter.

This parameter does not al-

low a value greater than 6 to

be set. Change the setting of

this parameter to a value not

greater than 6.

1503 2150 A value equal to or greater

than 10 is set.

Set a value less than 10.

1793 2179 A negative value or a value

greater than the setting of

PRM1821 is set.

Set a positive value less

than the setting of PRM

1821.
