19. MAINTENANCE FUNCTION

913

8 Display the following soft keys with soft key [(OPRT)].

F SRH DELETEN READF READ PUNCH

The operation of each function is the same as on the directory (memory

card) screen. Soft key [O SET], used for program number setting, and the

“PROGRAM NUMBER =” indication are not displayed for data items other

than program.

[F SRH] : Finds a specified file number.

[F READ] : Reads a specified file number.

[PUNCH] : Writes a file.

[N READ] : Reads a file under a specified file name.

[DELETE] : Deletes a specified file number.

19.1.5.7 Related parameters

0020

I/O CHANNEL: Selection of an input/output device

Setting value = 4

(The memory card interface is used for input/output.)

#6 #5 #4 #3 #2 #1 #0

0138

MDN MDP

[Data type] Bit

#0 (MDP) In data output by a memory card, the series information is:

0: Not added to the output file name.

1: Added to the output file name.

#7 (MDN) The DNC operation function by a memory card is:

0: Disabled.

1: Enabled. (A PCMCIA card attachment is required.)

#6 #5 #4 #3 #2 #1 #0

0300

PCM

#0 (PCM) If the CNC screen display function is enabled, when a memory

card interface is provided on the NC side (HSSB connection),

0 : The memory card interface on the NC side is used.

(The setting of PRM20 is followed.)

1 : The memory card interface on the PC side is used.
