18. MAINTENANCE INFORMATION

877

DWL: Program–specified dwell command (G04) is being executed.

***: Other status

(4) Auxiliary function status

FIN: The completion signal FIN for an auxiliary function is being awaited.

***: Other status

(5) Emergency stop and reset status (displayed at the location of items

mentioned in (3) and (4))

––EMG––

:Emergency stop status

–RESET–: CNC reset status (The state in which the reset signal or the

MDI (RESET) key remains active.)

(6) Alarm status

ALM

:An alarm condition has been detected.

BAT

: The lithium battery (CNC back–up battery) voltage is low (the

battery is to be replaced).

Blank: Other status

(7) Clock display: Hour:minute:second

(8) Program editing/running status

Input: Data is being input.

Output: Data is being output.

SRCH: A data search is under way.

EDIT: Editing such as insertion or modification is under way.

LSK: Label skip enabled at data input (until valid information is read).

PTRR: Retract or return/re–positioning is under way when the tool

retract and recover function is used.

HPCC: High–precision contour control mode.

AICC: AI contour control mode.

AI NANO: AI nano contour control mode

AI HPCC: AI high–precision contour control mode

NANO HP: AI nano high–precision contour control mode

AIAPC: AI advanced preview control mode

RVRS: Reversing based on the retrace function.

RTRY: Re–advancing based on the retrace function.

RVED: Reversing based on the retrace function has ended.

Blank: Editing is not under way.
