18.4 Warning Screen Displayed

When an Option Is Changed

878

18.4 Warning Screen Displayed When an Option Is

Changed

D Warning screen

This CNC displays a warning screen when the configuration of the options

using the SRAM area is changed. The data for the function indicated on the

screen is cleared the next time the system is turned on.

WARNING

YOU SET THE PARAMETER NO.jjjj#j

THE FOLLOWING DATA WILL BE CLEARED.

* PART PROGRAM MEMORY

PLEASE PRESS <DELETE> OR <CAN> KEY.

<DELETE> : CLEAR ALL DATA

<CAN> : CANCEL

NOTE Mark* varies with the parameter settings. Two or more function names

may be displayed.

D Allocation error screen

When an option which uses the SRAM area is added, the system software

may require more SRAM than is currently installed in the system. In this

case, an allocation error screen appears the first time the system is turned

on after the addition of the option, thus restoring the state existing before the

addition.

FILE ALLOCATION ERROR

S–RAM CAPACITY IS NOT SUFFICIENT.

ADDITIONAL S–RAM IS NECESSARY.

PLEASE PRESS <CAN> KEY :

RETURN TO THE STATE BEFORE

OPTION PARAMETER IS CHANGED.

NOTE When replacing SRAM, perform all memory clear.

(When turning on the power, press the MDI keys

RESET

and

DELETE
