GENERAL

B–63444EN/01

1. GENERAL

GENERAL

This manual consists of the following parts:

I. GENERAL

Describes chapter organization, applicable models, related manuals,

and notes for reading this manual.

II. PROGRAMMING

Describes each function: Format used to program functions in the NC

language, characteristics, and restrictions.

III. OPERATION

Describes the manual operation and automatic operation of a machine,

procedures for inputting and outputting data, and procedures for

editing a program.

IV. MAINTENANCE

Describes alarms, self–diagnosis, and procedures for replacing fuses

and batteries.

APPENDIX

Lists tape codes, valid data ranges, and error codes.

This manual does not describe parameters in detail. For details on

parameters mentioned in this manual, refer to the Connection and

Maintenance Manual (B–63445EN).

This manual describes all optional functions. Look up the options

incorporated into your system in the manual written by the machine tool

builder.

The models covered by this manual, and their abbreviations are:

Product name Abbreviations

FANUC Power Mate 0 Power Mate 0 Power Mate

This manual uses the following symbols:

I _

Indicates a combination of axes such as X__ Y__ Z

(used in PROGRAMMING.).

Indicates the end of a block. It actually corresponds to

the ISO code LF or EIA code CR.

;

About this manual

Applicable models

Special symbols
