FANUC POWER MATE 0 Operators manual Page 325

Operators manual

Page of 492

/ 492

OPERATION

B–63444EN/01

9. EDITING PROGRAMS

313

All programs registered in memory can be deleted.

Procedure for Deleting All Programs

1 Select the EDIT mode.

2 Press

PROG

to display the program screen.

3 Key in address

4 Key in –9999.

5 Press edit key

DELETE

to delete all programs.

1 Set the mode select switch to

EDIT.

2 Press the

PRGRM

button.

3 Key in address

4 Key in [–], [9], [9], [9], and [9] and push the <DELET> button.

Programs within a specified range in memory are deleted.

Procedure for Deleting More Than One Program by Specifying a Range

1 Select the EDIT mode.

2 Press

PROG

to display the program screen.

3 Enter the range of program numbers to be deleted with address and

numeric keys in the following format:

OXXXX,OYYYY

where XXXX is the starting number of the programs to be deleted and

YYYY is the ending number of the programs to be deleted.

4 Press edit key

DELETE

to delete programs No. XXXX to No. YYYY.

9.5.2

Deleting All Programs

Procedure for CRT/MDI

Procedure for DPL/MDI

9.5.3

Deleting More Than

One Program by

Specifying a Range

Procedure for CRT/MDI
