PROGRAMMING

2. CONTROLLED AXES

B–63444EN/01

No. of basic controlled axes 2 axes

Basic simultaneously controlled axes 2 axes

The axis name must always be X or Z.

Parameter No. 1020 is used to determine the name of each axis.

When this parameter is set to 0 or a character other than the valid

characters is specified, an axis name from 1 to 2 is assigned by default.

Be sure to set the X or Z axis name in parameter No. 1020.

When a default axis name (1 to 2) is used, operation in the MEM mode

and MDI mode is disabled.

If a duplicate axis name is specified in the parameter, operation is enabled

only for the axis specified first.

Name of in-

crement sys-

tem

Least input incre-

ment

Least command

increment

Maximum

stroke

IS–B

0.001mm

0.0001inch

0.001deg

0.001mm

0.0001inch

0.001deg

99999.999mm

9999.9999inch

99999.999deg

Combined use of the inch system and the metric system is not allowed.

There are functions that cannot be used between axes with different unit

systems. For the increment system, see the machine tool builder’s

manual.

Maximum stroke = Least command increment 99999999

See 2.3 Incremen System.

NOTE

1 A command which causes the maximum stroke to be

exceeded cannot be specified.

2 The actual stroke varies with the machine.

3 The maximum stroke is the diameter when a diameter is

specified or the radius when a radius is specified.

2.1

CONTROLLED AXES

2.2

AXIS NAME

Limitations

D Default axis name

D Duplicate axis names

2.3

INCREMENT SYSTEM

2.4

MAXIMUM STROKE
