OPERATION

B–63444EN/01

11. SETTING AND DISPLAYING DATA

351

By moving the tool until it reaches the desired reference position, the

corresponding tool offset value can be set.

Procedure for counter input of offset value

1 Manually move the reference tool to the reference position.

2 Reset the relative coordinates along the axes to 0 (see subsec.

III–11.1.2).

3 Move the tool for which offset values are to be set to the reference

position.

4 Select the tool compensation screen. Move the cursor to the offset

value to be set using cursor keys.

OFFSET/GEOMETRY O0001 N00000

NO. X Z. R T

001 0.000 1.000 0.000 0

002 1.486 –49.561 0.000 0

003 1.486 –49.561 0.000 0

004 1.486 0.000 0.000 0

005 1.486 –49.561 0.000 0

006 1.486 –49.561 0.000 0

007 1.486 –49.561 0.000 0

008 1.486 –49.561 0.000 0

ACTUAL POSITION (RELATIVE)

U 0.000 W 0.000

>X_

HND **** *** *** 16:05:59

[NO,SRH][ ][ INP.C. ][ +INPUT ][ INPUT ]

5 Press address key

(or

) and the soft key [INP.C.].

11.4.3

Counter Input of Offset

value
