OPERATION11. SETTING AND DISPLAYING DATA

B–63444EN/01

330

The table below lists the data set on each screen.

Table.11 Setting screens and data on them

No.

Setting screen Contents of setting

Reference

item

1 Tool offset value Tool offset value

Tool nose radius compensation value

Subsec. 11.4.1

Direct input of tool offset value Subsec. 11.4.2

Counter input of offset value Subsec. 11.4.3

2 Workpiece coordinate

system setting

Workpiece origin offset value Subsec. 11.4.5

3 Setting data (handy) Parameter write

TV check

Punch code (EIA/ISO)

Input unit (mm/inch)

I/O channel

Automatic insert of Sequence No.

Subsec. 11.4.4

4 Setting data (mirror

image)

Mirror image Subsec. 11.4.4

5 Setting data (timer) Parts required Subsec. 11.4.4

6 Macro variables Custom macro common variables

(#100 to #149)

(#500 to #531)

Subsec. 11.4.7

7 Parameter Parameter Subsec. 11.5.1

8 Pitch error Pitch error compensation data Subsec. 11.5.2

9 software operator’s

panel

Mode selection

Jog feed axis selection

Jog rapid traverse

Axis selection for Manual pulse

generator

Multiplication for manual pulse

generator

Jog feedrate

Feedrate override

Rapid traverse override

Optional block skip

Single block

Machine lock

Dry run

Protect key

Feed hold

Subsec. 11.4.8

D Setting screens
