OPERATION

B–63444EN/01

11. SETTING AND DISPLAYING DATA

359

With this function, functions of the switches on the machine operator’s

panel can be controlled from the CRT/MDI panel.

Jog feed can be performed using numeric keys.

Procedure for Displaying and Setting the Software Operator’s Panel

1 Press function key

OFFSET

SETTING

2 Press the continuous menu key

, then press chapter selection soft

key

[OPR].

3 The screen consists of several pages.

Press page key

PAGE

until the desired screen is displayed.

OPERATOR’S PANEL O0000 N00000

MODE : MDI MEM EDIT STEP JOG REF

HNDL FEED : DISABLE HX HZ

H/S MULTI. : ***(HNDL: *1 STEP: *1)

RAPID OVRD. : 100% 50% 25% F0

JOG FEED : 2.0%

**************

FEED OVRD. : 100%

***

ACTUAL POSITION (ABSOLUTE)

X 0.000 Z 0.000

MDI **** *** *** 16:05:59

[ MACRO ] [ ] [ OPR ] [ ] [(OPRT)]

OPERATOR’S PANEL O0000 N00000

BLOCK SKIP : OFF J ON

SINGLE BLOCK : J OFF ON

MACHINE LOCK : OFF J ON

DRY RUN : J OFF ON

PROTECT KEY : J PROTECT RELEASE

FEED HOLD : J OFF

ACTUAL POSITION (ABSOLUTE)

X 0.000 Z 0.000

S 0 T0000

MDI **** *** *** 16:05:59

[ MACRO ] [ ] [ OPR ] [ ] [(OPRT)]

4 Move the cursor to the desired switch by pressing cursor key or

11.4.8

Displaying and Setting

the Software

Operator's Panel

OPR

Continuous menu key
