OPERATION

2. OPERATIONAL DEVICES

B–63444EN/01

224

After a character or number has been input from the MDI panel, a data

check is executed when

INPUT

key or a soft key is pressed. In the case of

incorrect input data or the wrong operation a flashing warning message

will be displayed on the status display line.

Warning message display

Data input display

Soft key display

Status display

[ ] [ ] [ ] [ ] [ ]

EDIT WRONG MODE

Fig.2.2.5 Warning message display

Table 2.2.5 Warning Messages

Warning message

Content

FORMAT ERROR The format is incorrect.

WRITE PROTECT Key input is invalid because of memory protect

signal or the parameter is not write enabled.

DATA IS OUT OF RANGE The value searched exceeds the permitted

range.

TOO MANY DIGITS The input value exceeds the permitted number

of digits.

WRONG MODE Parameter input is not possible in any mode oth-

er than MDI mode.

EDIT REJECTED It is not possible to edit in the current CNC sta-

tus.

2.2.5

Warning Messages
