PROGRAMMING

4. INTERPOLATION FUNCTIONS

B–63444EN/01

Linear interpolation can be commanded by specifying axial move

following the G31 command, like G01. If an external skip signal is input

during the execution of this command, execution of the command is

interrupted and the next block is executed.

The skip function is used when the end of moving is not programmed but

specified with a signal from the machine, for example. It is used also for

measuring the dimensions of a workpiece.

G31 _ ;

G31: One–shot G code (If is effective only in the block in which

it is specified)

The coordinate values when the skip signal is turned on can be used in a

custom macro because they are stored in the custom macro system

variable #5061 to #5062, as follows:

#5061 X axis coordinate value

#5062 Z axis coordinate value

WARNING

Disable feedrate override, dry run, and automatic

acceleration/deceleration (with parameter No. 6200 and

subsequent parameters) when the feedrate per minute is

specified, allowing for an error in the position of the tool

when a skip signal is input. These functions are enabled

when the feedrate per rotation is specified.

4.6

SKIP FUNCTION

(G31)

Format

Explanations
