FANUC POWER MATE 0 Operators manual Page 54

Operators manual
PROGRAMMING
4. INTERPOLATION FUNCTIONS
B–63444EN/01
40
The command below will move a tool along a circular arc.
Arc in the ZpXp plane
G03
G02
Xp_ p_
I_ K_
R_
F_
Table.4.3 Description of the Command Format
Command Description
G02 Circular Interpolation Clockwise direction (CW)
G03 Circular Interpolation Counterclockwise direction (CCW)
X
p_
Command values of X axis or its parallel axis
(set by parameter No. 1022)
Z
p_
Command values of Z axis or its parallel axis
(set by parameter No. 1022)
I_ X
p
axis distance from the start point to the center of an arc
with sign
k_ Z
p
axis distance from the start point to the center of an arc
with sign
R_ Arc radius with sign fixed to radius designation.
F_ Feedrate along the arc
4.3
CIRCULAR
INTERPOLATION
(G02,G03)
Format
