OPERATION10. CREATING PROGRAMS

B–63444EN/01

320

Programs can be created in the EDIT mode using the program editing

functions described in Chapter 9.

Procedure for Creating Programs Using the MDI Panel

1 Enter the EDIT mode.

2 Press the

PROG

key.

3 Press address key

and enter the program number.

4 Press the

INSERT

key.

5 Create a program using the program editing functions described in

Chapter 9.

1 Select EDIT mode.

2 Press the <PRGRM> key.

3 Key in address O.

4 Enter the number of the program to be registered.

5 Press the <INSRT> key.

By pressing this key, the entered program number will be registered.

Enter each word of the program followed by the <INSRT> key to

Comments can be written in a program using the control in/out codes.

Example) O0001 (FANUC POWER Mate) ;

M08 (COOLANT ON) ;

⋅ When the

INSERT

key is pressed after the control–out code “(”,

comments, and control–in code “)” have been typed, the typed

comments are registered.

⋅ When the

INSERT

key is pressed midway through comments, to enter

the rest of comments later, the data typed before the

INSERT

key is

pressed may not be correctly registered (not entered, modified, or lost)

because the data is subject to an entry check which is performed in

normal editing.

10.1

CREATING

PROGRAMS USING

THE MDI PANEL

Procedure for CRT/MDI

Procedure for DPL/MDI

Explanation

D Comments in a program
